The isolated step-down DC/DC converter NP-DTDI30-60S196 is used to effectively reduce higher DC voltage in the range of 3060V DC to a stable output voltage of 19V DC. Thanks to the galvanic isolation of the input and output, it is suitable for professional and industrial applications where high operational safety, power supply stability and protection of sensitive electronics are required.
Technical specifications
Converter type: isolated DC/DC converter (step-down)
Input voltage: 3060V DC
Output voltage: 19V DC
Maximum output current: 6A
Maximum power: 114W
Dimensions: 74 × 74 × 32 mm
Weight: 300g
Protection: IP67
Cooling: passive, aluminum finned case
Electrical separation: galvanic isolation input/output
Functions and features
Step-down topology for efficient reduction of higher DC voltage
Galvanic isolation increases safety and reduces interference transmission
Stable output voltage of 19V DC even with input voltage fluctuations
Compact design with high performance
Robust aluminum housing ensures long life and good heat dissipation
Wire connection for quick and easy installation
Ideal for
Powering devices requiring 19V DC
Industrial and automation systems
Powering electronics from 36V, 48V or 60V DC distributions
Control units, modules and specialized technical devices
Applications requiring country separation and increased operational safety
Package contents
1× isolated DC/DC converter NP-DTDI30-60S196
Why choose this product?
Safe operation thanks to galvanic isolation
High power of 114W with uniform and compact dimensions
Durable design suitable for demanding operating conditions
Reliable solution for professional power applications
