CBB60 run capacitor is a running capacitor for AC motors. It is used to ensure correct phase shift and stable operation of single-phase motors in applications such as fans, pumps or compressors.
Technical specifications
Type: motor run capacitor
Series designation: CBB60
Capacitance: 20 µF
Rated voltage: 450 VAC
Frequency: 50/60Hz
Dielectric: polyester film
Temperature range: -25 to +85 °C
Capacity tolerance: ±5%
Body dimensions: 37 × 80 mm
Terminals: wires
Application: AC/motor
Functions and features
Designed for continuous operation in motor applications
Stable capacity over normal operating temperature range
Design suitable for installation in equipment with limited space
Suitable for applications with 50/60 Hz power supply
Ideal for
Single-phase asynchronous motors with auxiliary winding
Fans and air conditioning
Pumps
Compressors and refrigeration technology
Air conditioning units
Package contents
1x motor capacitor CBB60 20 µF
Why choose this product?
Standard design CBB60 for motor run capacitors
Rated voltage 450 VAC for general motor applications
Clearly defined mechanical dimensions of 37 x 80 mm for design and service
Wire outlets for direct connection to the device
Installation and operating instructions
Before installation, verify the required capacity and voltage class according to the device documentation.
Observe correct mechanical fastening and ensure that the terminals are protected against tension and vibration.
After disconnecting the power supply, wait for the capacitor to discharge, or perform a controlled discharge using a suitable resistor.
Safety notice
The product is designed to operate with a mains voltage of 230 VAC; incorrect handling may result in electric shock.
Carry out the installation only with the power supply disconnected and in accordance with the applicable electrical regulations.
The capacitor may remain charged even after power is removed; always verify discharge before touching the terminals.
