The WX110 / WX010 series wire-wound rotary potentiometer is designed for manual resistance adjustment in electrical and electronic circuits. It is suitable for applications where simple mechanical control, stable construction and the possibility of choosing from multiple resistance variants are required. The 3-terminal design allows use as a variable resistor and as a voltage divider.
Technical specifications
Model series: WX110 / WX010
Component type: rotary potentiometer
Number of pins: 3 pins
Construction: panel round design
Tolerance: ±5%
Available resistance options: 100 , 220 , 330 , 470 , 560 , 680 , 1 k, 2.2 k, 3.3 k, 4.7 k, 5.6 k, 6.8 k, 10 k, 22 k
Functions and features
Mechanical rotary resistance adjustment via shaft
Can be used as a variable resistor or resistor divider
Wire construction suitable for general control and adjustment applications
The metal housing contributes to the mechanical resistance of the component
Easy integration into panel-mounted devices
Wide selection of resistance values for different types of circuits
Ideal for
Electronic equipment service and repair
Laboratory preparations and measuring equipment
Adjustment and control circuits
Industrial and hobby electronic construction
Signal level control and manual adjustment of circuit parameters
Package contents
1 x rotary potentiometer WX110 / WX010 in the selected resistance variant
1x fixing nut
1x washer
Why choose this product?
Proven rotary potentiometer type for common technical use
Availability of multiple resistance variants within one design series
3-pin design for universal connection
Compact metal construction suitable for panel mounting
Suitable solution for applications requiring manual and continuous resistance adjustment
Installation and operating instructions
When selecting a resistance value, consider the requirements of the specific application and the way the potentiometer is connected.
Before assembly, verify the mechanical compatibility of the shaft, mounting and terminal spacing.
When soldering, we recommend limiting the thermal stress on the pins to the necessary minimum.
For proper operation, ensure adequate electrical load in accordance with the parameters of the application used.
