Descrizione
The round LED driver is a power supply for the current feeding of LED luminaires with an output current of 300 mA. It is used to convert AC mains voltage to a DC output for LED loads in the range of DC 24-42 V. It is designed for fixed installation in luminaires and lighting assemblies where a separate power supply module for LEDs is required.
Technical Specifications
Product type: LED driver
Power: 12 W
Input voltage: AC 180-265 V
Input frequency: 50/60 Hz
Output voltage: DC 24-42 V
Output current: 300 mA
Output current tolerance: ±5 %
Power factor: PF 0.9
Ambient operating temperature Ta: 45 °C
Case temperature Tc: 85 °C
Body dimensions: diameter 42 mm, height 22 mm
Design: round casing with connecting wires
Input wires: L, N
Output wires: LED+, LED-
Features and Properties
Converts AC mains voltage to DC current output for LEDs.
The output is marked with LED+ and LED- polarity for correct connection of the LED load.
The round casing allows installation in space-restricted parts of the luminaire.
Connection is handled by exposed wires without an integrated terminal block.
The casing features mounting brackets for mechanical fastening.
Ideal For
LED panel lights with corresponding electrical parameters.
LED ceiling lights with an external current driver.
LED downlights powered by a 300 mA current.
Replacing a damaged LED driver with an identical output current and corresponding output voltage range.
Package Contents
1× LED driver
Why Choose This Product
Suitable for LED loads with a current of 300 mA and an operating voltage of DC 24-42 V.
Features clearly marked input and output wires, including output polarity.
The compact round design is suitable for installation in LED luminaires.
Parameters are listed directly on the driver body, making it easy to check during installation or replacement.
Installation and Operating Instructions
Before installation, verify the compatibility of the output current and output voltage range with the connected LED load.
Connect the input wires only to the appropriate AC mains voltage.
Connect the output wires to the LED load with the correct LED+ and LED- polarity.
Secure the driver so that the wires are not subjected to mechanical stress.
Installation must be performed by a person with appropriate electrical qualifications.
Safety Warnings
The device operates with mains voltage; incorrect handling may result in electric shock.
Perform installation, dismantling, and wiring only when the power supply is disconnected.
Do not connect an LED load with an incompatible current or voltage range.
Incorrect connection of the output polarity will cause malfunction or damage to the LED load.
Do not use the driver if there is visible damage to the casing, wires, or insulation.
Ensure sufficient space for heat dissipation and do not exceed the specified Ta and Tc temperature values.
