Descrizione
Series: MC4
Contact system: MULTILAM
Gender: Receptacle
Contact material: Copper, tin plated
Insulation material: PC/PA
Degree of protection, mated: IP66/IP68 (1 m, 1 h)
Degree of protection, unmated: IP2X
Voltage rating: 1kV
Rated Impulse Voltage: 16 kV
Current rating: 30A
Max. contact resistance of the connector: 0.25 mO
Connector Mounting: Panel
Contact Termination Type: Crimp
Cable section: 4-6 mmq (12-10 AWG)
Ambient temperature range: -40 °C…+85 °C
Upper limiting temperature: 105 °C
SVHC: No SVHC (16-Jun-2014)
